FOSTEX RM-2

SKU: d8a560e8b81b Categories: ,

Description

FOSTEX RM-2



Ecoute de contrôle rackable 1u stéréo amplifiée

Specifications

Speaker Section
Unit:    110 x 40mm cone type, magnetically shielded, x 2
Impedance:    8 ohms
Output SPL:    84 dB/W (1m)
Frequency response:    200Hz to 20kHz
Amplifier Section
Rated output power:    10W or more (8 ohms, 1kHz)
Residual noise:    -60 dBV or less (DIN AUDIO)
Distortion:    0.5% or less (10W / 4 ohms, 1kHz)
Digital input
Connector:    XLR-3-31 type
Format:    IEC60958 (AES/EBU)
Sampling frequency:    44.1kHz to 96 kHz
Analog input
Connector:    XLR / 1/4″ combi-jack
Nominal input level    +4dBu (XLR), -10 DdBV (1/4″)
Input impedance    10k ohms or more
Phones
Connector:    1/4″ stereo jack
Applicable load imp.    8 ohms or more
Rated output power    20mW + 20mW (32 ohms, 1kHz)
Level meters:    26-dot LED meter x 2
When digital input is selected
Peak metering, 0dB: 0dBFS
When analog input is selected
VU metering, 0dB: +4DBu/-10dBV
General
External dimensions:    430(W) x 44(H) x 282(D) mm
Weight:    Approx. 3.5kg
Power requirement:    100 – 240V~, 50/60Hz
Power consumption:    10W
